Goodman GPG14M - 3 Ton Cooling - 40,000 BTU/Hr Heating - Packaged Gas/Electric Central Air System - 14 SEER - 81% AFUE - 208-230/1/60

Name: Goodman GPG14M - 3 Ton Cooling - 40,000 BTU/Hr Heating - Packaged Gas/Electric Central Air System - 14 SEER - 81% AFUE - 208-230/1/60
Brand: Goodman
SKU: 61971
Price: 3432.00 USD
Availability: OutOfStock

Model: GPG1436040M41 Item Number: 61971

Ask a Question

Enlarge Image

View All

Specification Highlights

Condition

New

This product is new and has never been used. It's in its original packaging, which has not been opened.

Weight

449 Pounds

Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.

Product Category

Packaged HVAC Unit

UPC

663051541337

Recommended Accessories

Required Accessories Add All Required

Installation Accessories

Features

Overview for Goodman GPG1436040M41

Goodman's packaged units are the perfect all-in-one comfort solution for nearly any residential application. The GPG14M is a packaged gas/electric central air system. It combines a gas-fired furnace, air conditioning condenser, evaporator coil, and ECM blower into a single unit. The GPG1436040M41's heat exchanger and coil feature Goodman's superior designs that ensure efficient operations whether your home needs heating or cooling. Replacing your split system with a GPG14M package is a breeze. This unit is equipped for either downflow or horizontal airflow and it features access panels to expedite installation. Streamline your comfort today with this Goodman packaged unit.

Aluminized-Steel Heat Exchanger

The GPG14M's furnace employs a reliable dual-diameter tubular heat exchanger design. Aluminized-steel is used for incredibly efficient heat transfer, and a wrinkle-bend is applied to the tubes to enhance the heat exchanger's dependability and longevity.

High-Efficiency Coils

The condenser coil of this packaged unit is designed with aluminum fins and rifled copper tubing to maximize surface area and efficiency. It also features a durable all-aluminum evaporator coil that optimizes heat transfer

Secure Design

The cabinet of the GPG1436040M41 is built to last. A galvanized steel casing and UV-resistant powder paint prevent fading and corrosion. Louvered panels and a coil guard are employed to keep the most important components secure.

Filter Drier

A filter drier is installed in the liquid line of this packaged unit's air conditioner. The filter drier removes moisture and traps impurities, preventing corrosion, freezing, and blockages that can negatively impact the operation of the condenser.

Quiet Comfort

A sound insulated blower compartment means that the GPG1436040M41 provides year-round comfort without disrupting your home.

Extended Warranty

Goodman offers a 10-year limited parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See warranty sheet under the "Manuals" tab for more information.

Product Note

The Goodman 20464501PDGK Horizontal Duct Cover Kit is required for downflow installation. NOTE: Due to DOE regulations, as of January 1st this unit can no longer be installed in the southwest and southeast DOE regions.

Specifications

Overview

Product Category

Packaged HVAC Unit

UPC

663051541337

General Information

Type

Gas/Electric Packaged Unit

Product Line

GPG14

Product Category

Packaged HVAC Unit

Operating Mode

Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements.

Heating and Cooling

Fuel Type

To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.

Natural Gas

Modulating/Staging

Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control.

Single Stage

Refrigerant Type

R-410A

Blower Motor Speed

Multi-Speed

Motor Type

ECM

Configuration

Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.

Downflow/Horizontal

Installation Location

Outdoor

Gas Conversion Kit

Available

Compressor Stages

Stages are the distinct levels of output that an air conditioner or heat pump can deliver. Having more than one stage allows the equipment to better match the needs of the space and deliver better comfort and more efficiency.

Single Stage

DOE Regional Compliance

In 2015, the US Department of Energy broke the country into three regions - North, Southeast, and Southwest - and set legal standards for energy efficiency within each region.

Nationwide (Except CA)

Performance

AFUE

AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace.

81 %

Capacity

Tonnage, or tons of cooling, is a short hand method for describing the capacity of cooling equipment. One ton is equal to approximately 12 kBTU/hr.

3.0 Tons

Cooling Capacity

34000 BTU

Heating Capacity

40000 BTU

SEER

SEER (Seasonal Energy Efficiency Ratio) is a measurement of cooling efficiency over a typical cooling season. It is useful for comparing energy efficiency of cooling systems. The higher the SEER, the more energy efficient the system.

14.0

EER

EER (Energy Efficiency Ratio) is a measurement of cooling efficiency under fixed conditions. It is useful for comparing units that will operate consistently under one set of conditions (e.g. server room). The higher the EER, the more efficient the system.

11.0

Maximum Air Flow

1440 CFM

Minimum Air Flow

1180 CFM

Maximum Sound Level

Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.

78 dB

Electrical Data

Voltage

208/230 Volts

Phase

Frequency

60 Hz

Minimum Circuit Ampacity

23 Amps

Recommended Breaker Size

35 Amps

Dimensions

Product Height

34 3/4 Inches

Product Width

47 Inches

Product Depth

51 Inches

Product Weight

449 Pounds

Shipping Weight

470 Pounds

Certifications

ETL Listed

Yes

AHRI Certified

Yes

ISO Certified

Yes

AHRI Reference Number

7505445

Warranty Information

Parts Warranty

A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More

10 Limited Years

Heat Exchanger Warranty

10 Limited Years

Compressor Warranty

Limited* 10 Years
