Emerson Ignition Module/Circulator Control Kit & Nitride Ignitor

Model: 21V51U-843 Item Number: 35857
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
White Rodgers 21V51U-843
PREVIOUS
NEXT
White Rodgers 21V51U-843
Enlarge Image
Our Price: $248.12
synchrony card icon
$42 / Month
Suggested monthly payments with 6 month financing.
Click for important monthly payment and offer information.
In-Stock
Ships Wednesday, April 17th
Shipping to60601
Emerson Ignition Module/Circulator Control Kit & Nitride Ignitor
Emerson Ignition Module/Circulator Control Kit & Nitride Ignitor Model: 21V51U-843 Item Number: 35857
$248.12
In-Stock
-
+
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Ask A Question
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Thermostats and Controls
    UPC
    786710540714
View More
Features
View More

Features

Overview for White Rodgers 21V51U-843

The 50V51-843 is a two-stage automatic gas interrupted ignition control employing a microprocessor to continually monitor, analyze, and control the proper operation of the gas burner and inducer. The 50V51-843 provides signals for proper operation of a variable fan speed circulator blower. Signals interpreted during continual surveillance of the two stage thermostat and flame sensing element initiate automatic ignition of the burner, sensing of the flame, and system shutoff during normal operation. The control incorporates system fault analysis for quick gas flow shutoff, coupled with automatic ignition retry upon sensing a fault correction. Includes: a 50V51-843 Ignition Control Module, a 21D64-2 Ignitor Kit, and a Set of Interconnect Harnesses (for Goodman).
  • White Rodgers 21V51U-843 Features
  • 120 VAC Ignitor Output
  • 120 VAC Two-Speed Inducer Output
  • 120 VAC Humidifier Output
  • 120 VAC Electronic Air Cleaner Output
  • 2-Stage Gas Valve Output
  • 16-Pin Variable Speed Circulator Output
  • OEM Application Dipswitch Selectable
  • Fuse Protection 3 Amp
  • Furnace Status LED Tri-Color (Green, Red and Amber)
  • CFM LED (Green)
  • Heat Fan OFF Delay (Dipswitch Selectable)
  • Fan ON Delay for Cooling
  • Auto Second Stage Delay (Dipswitch Selectable Mode)
  • Historical Fault Retrieval by Pushbutton
  • YLO, Y, W, W2, R, G, C, O, BK/DS/Dehum Terminals
  • Pressure Switch Inputs and Monitoring
  • Flash Microprocessor with Non-Volatile Memory
  • Flame Current Measurement Points
    • Specifications
    View More

    Specifications

    Overview
    Product Category
    Thermostats and Controls
    UPC
    786710540714
    General Information
    Type
    Ignitor
    Product Category
    Thermostats and Controls
    Warranty Information
    Warranty Learn More
    Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab.
    1 Year
