Watts Radiant M-Series - 2-Port - Stainless Steel Manifold - Complete Kit - 1" Trunk - 3/4" BSP Ports

Model: D3803002SS-KIT Item Number: 25544
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Watts Radiant D3803002SS-KIT
PREVIOUS
NEXT
Watts Radiant D3803002SS-KIT
Enlarge Image
Our Price: $468.30
synchrony card icon
$79 / Month
Suggested monthly payments with 6 month financing.
Click for important monthly payment and offer information.
Factory-Direct
Ships in 4-7 Business Days
Watts Radiant M-Series - 2-Port - Stainless Steel Manifold - Complete Kit - 1
Watts Radiant M-Series - 2-Port - Stainless Steel Manifold - Complete Kit - 1" Trunk - 3/4" BSP Ports Model: D3803002SS-KIT Item Number: 25544
$468.30
Factory-Direct
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Ask A Question
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Boiler Accessories
    UPC
    840213105730
View More
Ports
Select Attribute
Type
Select Attribute
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Watts Radiant D3803002SS-KIT

Watts Radiant stainless steel manifolds combine the benefits of high-grade materials with fantastic engineering to deliver a complete, effective manifold package. High-grade, heavy-walled stainless steel gives the manifold unrivaled strength against both corrosion and bursting, along with a professional appearance. Flowmeter valves allow for easy circuit isolation for repairs or maintenance, while a full array of brass and nickel fittings allows Watts Radiant stainless steel manifolds to fill nearly any role imaginable.
  • Included Trunk Isolation Valve Kit
  • This trunk isolation ball valve kit includes two isolation ball valves, a vent-and-purge assembly, and a manifold end cap. It provides the ability to isolate the manifold from the rest of the circuit at will.
  • Top Grade Steel
  • Watts Radiant SST20 manifolds are built around a heavy-walled stainless steel trunk. The grade of steel used gives the manifold unparalleled corrosion resistance and the durability needed to last for years.
  • Included Flow Balancing Valves and Flow Meters
  • The SST20 manifold comes with flow meters and balancing valves standard. The flowmeters allow for a complete flow rate readout at a glance, while the balancing valves allow for quick and easy flow balancing across all circuits.
  • Fast and Easy to Install
  • The included, pre-mounted manifold brackets keep installation time to an absolute minimum. This means you'll save both time and money when compared to installation of other manifolds.
  • Full Line of Accessories
  • Watts Radiant SST20 stainless steel manifolds feature a full line of quality accessories and fittings to compliment the manifold itself. These fittings are made of solid brass plated by nickel to resist corrosion and match the appearance of the manifold.
  • Product Includes
  • (1) Watts Radiant SST20 Manifold
  • (1) Vent-and-Purge Assembly
  • (1) Manifold End Cap
  • (2) Trunk Isolation Ball Valves
    • Specifications
    View More

    Specifications

    Overview
    Product Category
    Boiler Accessories
    UPC
    840213105730
    General Information
    Product Line
    SST20
    Product Category
    Boiler Accessories
    Number of Circuits
    2
    Material
    Stainless Steel
    Supply Connection Type
    BSP
    Return Connection Type
    BSP
    Performance
    Maximum Operating Temperature
    167 F
    Maximum Operating Pressure
    87 PSI
    Dimensions
    Supply Connection
    1 Inch
    Return Connection
    1 Inch
    Product Height
    11 3/4 Inches
    Product Width
    7 5/8 Inches
    Product Depth
    3 3/8 Inches
    Shipping Weight
    11 Pounds
    Certifications
    Country of Origin
    United States
    Warranty Information
    Warranty Learn More
    Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab.
    1 Year
