Taco 1/25 HP Cast Iron Variable Speed Cartridge Circulator

Model: 007-VSF5 Item Number: 33193
Ask a Question
Taco 007-VSF5
PREVIOUS
NEXT
Taco 007-VSF5
Enlarge Image
Product Discontinued
Sorry, this product is no longer available.
Specification Highlights
    Condition
    New Learn More
    Weight
    8 Pounds Learn More
    Type
    Circulator
    Product Line
    007 Series
View More
Features
View More

Features

Overview for Taco 007-VSF5

Variable speed circulators are one of the best ways to improve circulation, and system efficiency. Taco's variable speed setpoint circulators will maintain a user-set fixed temperature or differential through shifting system conditions and demands. By scaling circulation and temperature mixing to your specific needs" to "By constantly monitoring system conditions and adjusting speed to match current conditions, the variable speed setpoint circulator improves system efficiency. The universal flange-to-flange dimension of Taco's "00" series circulators makes installation quick, even if you are replacing a different pump. With Taco, your hydronic circulation is in good hands.
Product Note
Cast iron cannot be used in domestic hot water or potable water applications.
Specifications
View More

Specifications

General Information
Type
Circulator
Product Line
007 Series
Motor Type
Variable Speed
Connection Type
Flanged
Material
Cast Iron
Flange Orientation
Standard
DHW Compatible Learn More
No
UPC
687752379570
Performance
Maximum Head
10 Feet
Maximum Flow Rate
23 GPM
Maximum Fluid Temperature
240 F
Horsepower
1/25
Maximum Operating Pressure
125 PSI
RPM
3250 RPM
Electrical Data
Voltage
115 Volts
Phase
1
Frequency
60 Hz
Current Draw
0.71 Amps
Dimensions
Product Height
6 3/8 Inches
Product Width
4 3/4 Inches
Product Depth
6 3/8 Inches
Product Weight
8 Pounds
Shipping Weight
9 Pounds
Certifications
UL Listed
Yes
NSF Certified Learn More
Yes
Warranty Information
Warranty Learn More
3 Years
