Little Giant LSPH-200-C 2 HP High-Pressure Cast Sprinkler Pump 55 PSI

Model: 558298 Item Number: 10263
Little Giant 558298
PREVIOUS
NEXT
Little Giant 558298
Little Giant 558298
Enlarge Image
Little Giant 558298
Little Giant 558298
View All
Our Price: $1,325.60

Only 2 In-Stock
Ships Thursday, February 29th
Shipping to60601
Little Giant LSPH-200-C 2 HP High-Pressure Cast Sprinkler Pump 55 PSI
Little Giant LSPH-200-C 2 HP High-Pressure Cast Sprinkler Pump 55 PSI Model: 558298 Item Number: 10263
$1,325.60
Only 2 In-Stock
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Water Pump
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Little Giant 558298

  • 2 HP Lawn High-Pressure Sprinkler Pump
  • For use in underground or above ground lawn sprinkling systems
  • Provides up to 55 Max PSI
  • Heavy-Duty Cast Iron Housing & Seal Plate
  • Designed for years of service and reliability
  • 230 Volt Heavy-Duty Century Motor (3450 RPM)
  • Low amp draw w/ single-phase capacitor start
  • Self-Priming Design w/ Priming Plug
  • After initial fill, no additional priming required
  • 5/8" Rotating Mechanical Seal
  • Provides a reliable seal agaisnt water leakage
  • Brass Impeller, Engineered Thermoplastic Diffuser Nozzle & Venturi
  • Designed for the highest pump efficiency and longevity
  • Buna-N Elastomers, Carbon-Ceramic Seal & SS Motor Shaft
  • Provides corrosion resistance and 110°F max operating temperature
  • Built-In Drain Plug
  • Makes it easy to drain the pump before storage
  • 2-Year Warranty
  • Specifications
    View More

    Specifications

    General Information
    Product Category
    Water Pump
    Motor
    Voltage
    240 Volt Single-Phase
    Running Amps
    11.2
    Pump
    Gallons Per Minute
    85 Gallons
    Inlet Diameter
    2 Inch
    Outlet Diameter
    1-1/2 Inch
    Self Priming
    Yes
    Pump Housing Drain
    Yes
    Mechanical Seal Material
    Ceramic Carbon
    Housing Material
    Cast Iron
    Impeller Material
    Brass
    Suction Head
    25 Feet
    Maximum PSI
    55
    Total Head Lift
    125 Feet
    Submersible
    No
    Engine
    Horsepower
    2 hp
    Overview
    Product Category
    Water Pump
    Weight
    73 Pounds
    Consumer Warranty
    2 Years
    Product Length
    21 Inches
    Product Width
    12 Inches
    Product Height
    12? Inches
    UPC
    010121141049
