LG LS303HLV3 30,000 BTU 20.0 SEER Ductless Mini Split Heat Pump System

Model: LS303HLV3 Item Number: 106691
Ask a Question
LG LS303HLV3
PREVIOUS
NEXT
LG LS303HLV3
LG LS303HLV3
LG LS303HLV3
Enlarge Image
LG LS303HLV3
LG LS303HLV3
LG LS303HLV3
View All
Originally $2,298.00, you save 5%
Our Price: $2,183.10
synchrony card icon
$364 / Month
Suggested monthly payments with 6 month financing.
In-Stock
Ships in 1-2 Business Days
LG LS303HLV3 30,000 BTU 20.0 SEER Ductless Mini Split Heat Pump System
LG LS303HLV3 30,000 BTU 20.0 SEER Ductless Mini Split Heat Pump System Model: LS303HLV3 Item Number: 106691
$2,183.10
In-Stock
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Truck Icon
Free Lift Gate Learn More
Specification Highlights
    Condition
    New Learn More
    Weight
    188.7 Pounds Learn More
    Type
    Wall Mounted
    Product Sub-line
    Extended Piping
View More
Bundle Includes 2 items
  • product image
    (1) LG - 30k BTU - Outdoor Condenser - For Single-Zone Only (LSU303HLV3)
  • product image
    (1) LG - 30k BTU - Wall Mounted Indoor Unit - For Single-Zone Only (LSN303HLV3)
View Full Bundle
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features & Bundle Details
View More

Features & Bundle Details

Overview for LG LS303HLV3

LG Single Zone Extended Pipe systems include advanced technology for cost-effective, energy efficient operation and improved piping capability to allow longer pipe length and higher elevation differences. These systems are available in heat pump configurations with 24,000, 30,000, and 36,000 Btu/h capacities. Over the years, LG has strived to meet the demand for high quality air conditioning solutions with greater energy efficiency, helping the environment while also reducing electricity costs for consumers.
Bundle Includes 2 items
  • product kit image
    LG - 30k BTU - Outdoor Condenser - For Single-Zone Only
    Model: LSU303HLV3
    Item Number: 106117
    Quantity: 1
  • product kit image
    LG - 30k BTU - Wall Mounted Indoor Unit - For Single-Zone Only
    Model: LSN303HLV3
    Item Number: 106116
    Quantity: 1
Specifications
View More

Specifications

Included In This Bundle

Bundle Overviewgrey arrow icon
Bundle Overview
LSU303HLV3 Specifications
LSN303HLV3 Specifications
General Information
Type
Wall Mounted
Product Sub-line
Extended Piping
Operating Mode Learn More
Heating and Cooling
Number of Zones Learn More
1
Refrigerant Type
R-410A
Indoor Unit Size(s) Learn More
30
Outdoor Unit Size
30000 BTU
DOE Regional Compliance Learn More
Nationwide
Line Set Size
3/8" x 5/8"
Performance
Cooling BTU
30000
Cooling Capacity
30000 BTU
Heating Capacity
32400 BTU
SEER Learn More
20.0
EER Learn More
11.3
HSPF Learn More
11.5
Cooling Power Input
2660 Watts
Heating Power Input
2750 Watts
Low Ambient Heating
Yes
Minimum Outdoor Temperature for Heating Learn More
-4 F
Minimum Outdoor Temperature for Cooling
14 F
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Recommended Breaker Size
30 Amps
Dimensions
Gas Connection Size
5/8 Inch
Liquid Connection Size
3/8 Inch
Product Weight
188.7 Pounds
Shipping Weight
209.2 Pounds
Certifications
UL Listed
Yes
ETL Listed
Yes
Energy Star Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
AHRI Reference Number
204825183
Warranty Information
Parts Warranty Show ACW Parts Warranty Learn More
5 Years
Compressor Warranty
7 Years
General Information
Type
Outdoor Condenser
Product Line
Extended Pipe
Operating Mode Learn More
Heating and Cooling
Multi-Zone Compatible
No
Refrigerant Type
R-410A
Installation Location
Outdoor
Performance
Cooling BTU
30000
Maximum Sound Level Learn More
58 dB
Low Ambient Heating
Yes
Minimum Outdoor Temperature for Heating Learn More
-4 F
Minimum Outdoor Temperature for Cooling
14 F
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
23 Amps
Recommended Breaker Size
30 Amps
Dimensions
Maximum Line Length
164 Feet
Gas Connection Size
5/8 Inch
Liquid Connection Size
3/8 Inch
Product Height
32 3/4 Inches
Product Width
37 1/2 Inches
Product Depth
15 1/2 Inches
Product Weight
147.9 Pounds
Shipping Weight
160.3 Pounds
Certifications
ETL Listed
Yes
UL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty Learn More
5 Years
Compressor Warranty
7 Years
General Information
Type
Wall Mounted
Product Line
Extended Pipe
Operating Mode Learn More
Heating and Cooling
Multi-Zone Compatible
No
Refrigerant Type
R-410A
Remote Control
Wireless
Indoor Unit Size(s) Learn More
30
Installation Location
Indoor
Performance
Cooling BTU
30000
Cooling Capacity
30000 BTU
Heating Capacity
32400 BTU
Maximum Air Flow
1166 CFM
Minimum Air Flow
601 CFM
Minimum Sound Level
33 dB
Maximum Sound Level Learn More
51 dB
Electrical Data
Phase
1
Frequency
60 Hz
Dimensions
Gas Connection Size
5/8 Inch
Liquid Connection Size
3/8 Inch
Product Height
14 5/8 Inches
Product Width
47 1/4 Inches
Product Depth
10 7/16 Inches
Product Weight
40.8 Pounds
Shipping Weight
48.9 Pounds
Certifications
ETL Listed
Yes
UL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty Learn More
5 Years
