Honeywell Prestige IAQ Kit w/ RedLINK Thermostat EIM & 2 Duct Sensors

Model: YTHX9421R5085WW Item Number: 84354
5.0 out of 5 stars5.0 out of 5 stars
(1)
Ask a Question
Honeywell YTHX9421R5085WW
PREVIOUS
NEXT
Honeywell YTHX9421R5085WW
Enlarge Image
Our Price: $264.70

In-Stock
Ships Wednesday, May 12th
Honeywell Prestige IAQ Kit w/ RedLINK Thermostat EIM & 2 Duct Sensors
Honeywell Prestige IAQ Kit w/ RedLINK Thermostat EIM & 2 Duct Sensors Model: YTHX9421R5085WW Item Number: 84354
$264.70
In-Stock
-
+
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Specification Highlights
    Condition
    New Learn More
    Type
    Thermostat
    Stages
    1 Heat/1 Cool
    Switch Contact Type
    Digital
View More
Features
View More

Features

Overview for Honeywell YTHX9421R5085WW

Overview for Honeywell YTHX9421R5085WW

The Prestige IAQ thermostat is a 2 wire high definition color touch screen thermostat, 7 day programmable and selectable for residential or light commercial use. Controls up to 4-stages of heat and 2-stages of cool in a heat pump system and up to 3-stages of heat and 2-stages of cool in a conventional system. Three sets of Universal IAQ contacts to control humidification, dehumidification, and ventilation. Four sensor inputs for wired sensors or dry contact devices. Works with the Equipment Interface Module and RedLINK accessories including the RedLINK Internet Gateway, Portable Comfort Control, Wireless Outdoor Sensor and Wireless Indoor Sensor.
  • Multiple staging options to provide comfort or energy savings.
  • Precise temperature control ( + / - 1 F ) for reliable and consistent temperature.
  • Tri-lingual - English, French and Spanish display options.
  • Extend wireless range of the Equipment Interface Module by connecting a THM4000R1000 Wireless Adapter to the ABCD terminals.
  • 4 assignable inputs on the Equipment Interface Module can be used with wired outdoor, indoor or discharge sensors, occupancy sensor for remote setback and dry contact devices to trip pre-packaged.
  • 3 assignable outputs to control humidification, dehumidification, ventilation and a stage of heating or cooling.
  • USB port for adding the dealer's full color business logo on the screen.
  • USB port for transferring Installer Setup, Customizable Reminders, Custom Events and Holidays to multiple thermostats.
  • Customizable Service Reminders allow dealers to remind their customers when its time to call for service, when their warranty is expiring and to provide customized alerts.
  • Performance Logs - Keeps a history of heating and cooling performance.
  • Alerts and User Interactions Log - Keeps a searchable history of alerts and setting changes to the thermostat to determine if there is a system malfunction or if the issue was caused by user error.
  • All Prestige IAQ kits come standard with a return and discharge air temperature sensor to measure Delta T.
  • Delta T Alerts and Diagnostics informs customers when their system is not performing as expected with instructions to contact the dealer. Provides a sense of security and greater comfort while generating repeat business.
  • Light commercial - commercial language ( occupied and unoccupied ), schedule holidays and custom events, remote setback, economizer and time of day.
  • Selectable for residential and light commercial applications. Meets commercial code and is title 24 compliant.
  • Increase profit per job by including RedLINK accessories that provide comfort and convenience.
  • RedLINK wireless communication.
  • Patented interview based programming and installer setup.
  • Smart Schedule - programs in seconds for any lifestyle
  • Control heating, cooling and IAQ equipment with only 2 wires at the thermostat. Heating, cooling and IAQ equipment wires to the Equipment Interface Module.
  • Our SKU number(s): Honeywell YTHX9421R5085WW
  • The manufacturer model number(s): Honeywell YTHX9421R5085WW
    • Specifications
    View More

    Specifications

    General Information
    Type
    Thermostat
    Stages
    1 Heat/1 Cool
    Switch Contact Type
    Digital
    System Type
    Heating + Cooling
    Voltage Type
    18 - 30
    Programmable
    Yes
    Power Source
    Hardwired
    Interface
    Digital
    Internet Connectivity
    Yes
    UPC
    085267336451
    Dimensions
    Product Height
    3 1/2 Inches
    Product Width
    4 1/2 Inches
    Product Depth
    7/8 Inch
    Reviews
    5.0 out of 5 stars5.0 out of 5 stars
    (1)
    View More

    Reviews

    Product Q&A
    View More

    Product Q&A

    Be the first to ask a question.

    Whether it's a general or technical question ACWholesalers can help. Our customer service team is backed by years of experience so you can have confidence knowing that you'll be getting an insightful response.
