Grundfos UP - 1/25 HP - Single Speed Circulation Pump - Bronze - Union - With Line Cord

Model: 99452457 Item Number: 103020
Grundfos 99452457
Grundfos 99452457
Enlarge Image
Our Price: $483.00
synchrony card icon
$81 / Month
Suggested monthly payments with 6 month financing.
Only 1 In-Stock
Ships Friday, June 9th
Shipping to60601
Grundfos UP - 1/25 HP - Single Speed Circulation Pump - Bronze - Union - With Line Cord
Grundfos UP - 1/25 HP - Single Speed Circulation Pump - Bronze - Union - With Line Cord Model: 99452457 Item Number: 103020
Only 1 In-Stock
Product Q&A
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Specification Highlights
    New Learn More
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    7 Pounds Learn More
    7 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Product Category
    Boiler Accessories
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
View More


Overview for Grundfos 99452457

Grundfos pumps offer the pinnacle of reliability and performance for a large variety of water circulation applications. From home hydronic circulation to large scale commercial water movement, Grundfos has a pump that will provide years of trouble-free service. The UP15-10BUC5/TLC is a single speed circulator with an integrated flow check valve, limiting water flow to a single direction. Solid bronze construction guarantees years of reliable performance with minimal maintenance needs, while hardwire electrical connection design allows the pump to tap directly into your home's electrical supply.
  • Durable Bronze Construction
  • The Grundfos UP15-10BUC5/TLC is crafted from bronze, which gives the pump both extended lifespan and protection against corrosion.
  • Whisper Quiet Operation
  • The UP15-10BUC5/TLC pump runs quiet even at high flow levels, ensuring the pump won't distract you from your work or disrupt your sleep.
  • Resilient Wet-Rotor Fluid Movement
  • The wet rotor design of the UP15-10BUC5/TLC lends integrity to both the motor and the rotor itself, providing exceptional longevity to any hydronic system the pump is a part of.
  • Product Includes
  • UP15-10BUC5/TLC
  • Timer
  • Line Cord
  • Check Valve
  • Specifications
    View More


    Product Category
    Boiler Accessories
    General Information
    Product Line
    Product Category
    Boiler Accessories
    Motor Type
    Single Speed
    Connection Type
    Union Mount
    Drive Type
    Wet Rotor
    DHW Compatible Learn More
    DHW Compatible
    Can be used in Domestic Hot Water applications (baths, sinks, showers).
    Maximum Head
    6.56 Feet
    Maximum Flow Rate
    6.5 GPM
    Minimum Fluid Temperature
    36 F
    Maximum Fluid Temperature
    220 F
    Maximum Operating Pressure
    145 PSI
    Electrical Data
    115 Volts
    60 Hz
    Product Height
    5 5/16 Inches
    Product Width
    5 Inches
    Product Depth
    4 5/16 Inches
    Product Weight
    7 Pounds
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    2 Years
