Goodman 2 Ton 18 SEER Heat Pump Condenser 2 Stage Communicating

Model: GSZC180241 Item Number: 82414
Ask a Question
Goodman GSZC180241
PREVIOUS
NEXT
Goodman GSZC180241
Goodman GSZC180241
Goodman GSZC180241
Goodman GSZC180241
Enlarge Image
Goodman GSZC180241
Goodman GSZC180241
Goodman GSZC180241
Goodman GSZC180241
View All
Our Price: $2,721.00
synchrony card icon
$48 / Month
With our 86 months 11.99% APR*
86 fixed monthly payments required.
Ships in 4-6 Weeks
Goodman 2 Ton 18 SEER Heat Pump Condenser 2 Stage Communicating
Goodman 2 Ton 18 SEER Heat Pump Condenser 2 Stage Communicating Model: GSZC180241 Item Number: 82414
$2,721.00
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Truck Icon
Free Lift Gate Learn More
Specification Highlights
    Condition
    New Learn More
    Weight
    230 Pounds Learn More
    Type
    Condenser
    Product Line
    GSZC18
View More
Size (Tons)
Learn More
Select Attribute
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Goodman GSZC180241

Goodman established itself as the largest HVAC manufacturer in the US by producing high-quality, efficient equipment for homeowners at a great value. The GSZC18 heat pump is an incredibly efficient heating and cooling solution. With a SEER rating of 18 and an HSPF rating up to 10.0, you can count on low energy usage regardless of the application. The savings don't stop at energy costs though; the GSZC180241's design reduces installation and service times. It features a two-stage compressor to ensure steady comfort and includes advanced components that protect the coil and compressor for peace of mind and reliable operations.
  • R-410A chlorine-free refrigerant
  • Two-Stage Copeland® UltraTech scroll compressor
  • High-density foam compressor sound blanket
  • ComfortNet Communicating System compatible
  • Expanded ComfortAlert diagnostics built in
  • Set-up capable with two low-voltage wires to outdoor unit
  • Diagnostic indicator lights and storage of six fault codes
  • Color-coded terminal strip for non-communicating set-up
  • SmartShift technology to ensure quiet, reliable defrost
  • Factory-installed bi-flow liquid line filter drier
  • Factory-installed suction line accumulator
  • Factory-installed compressor crankcase heater
  • Factory-installed high-capacity muffler
  • Factory-installed coil and ambient temperature sensors
  • High- and low-pressure switches
  • Charged for up to 15' of tubing length
  • Two-speed quiet condenser fan motor
  • Sweat connection service valves with easy access to gauge ports
  • AHRI Certified; ETL Listed
  • Wire fan discharge grille
  • Steel louver coil guard
  • Baked-on powder paint finish
  • Rust-resistant coated screws
  • Compact footprint
  • Top and side maintenance access
  • Single-panel access to controls with space provided for field-installed accessories
  • When properly anchored, meets the 2010 Florida Building Code unit integrity requirements for hurricane-type winds (Anchor bracket kits available.)
  • Our SKU number(s): Goodman GSZC180241
  • The manufacturer model number(s): Goodman GSZC180241
  • Product Note
    The recommended line set size for this unit will vary based on the length of line set you require for installation. Compatible line sets can be found under the "Accessories" tab. | The US Department of Energy regulates minimum efficiency standards for central air conditioners and heat pumps based on geographic regions. We are required to abide by these regulations when selling products, and take this responsibility seriously. The standards depend on the rated efficiency of the entire system, not the nominal efficiencies of individual components. If you are unsure if your system will be compliant, please call or email us for help.
    Specifications
    View More

    Specifications

    General Information
    Type
    Condenser
    Product Line
    GSZC18
    Operating Mode Learn More
    Heating and Cooling
    Refrigerant Type
    R-410a
    Installation Location
    Outdoor
    Compressor Stages Learn More
    Two
    DOE Regional Compliance Learn More
    Nationwide
    UPC
    663051563841
    Performance
    Capacity Learn More
    2.0 Tons
    Cooling BTU
    24000
    Cooling Capacity
    24000 BTU
    Heating Capacity
    23000 BTU
    SEER Learn More
    18.0
    Maximum Sound Level Learn More
    68 dB
    Electrical Data
    Voltage
    208/230 Volts
    Phase
    1
    Frequency
    60 Hz
    Minimum Circuit Ampacity
    15 Amps
    Recommended Breaker Size
    25 Amps
    Dimensions
    Suction Connection Size
    7/8 Inch
    Liquid Connection Size
    3/8 Inch
    Product Height
    40 Inches
    Product Width
    35 1/2 Inches
    Product Depth
    35 1/2 Inches
    Product Weight
    230 Pounds
    Shipping Weight
    250 Pounds
    Certifications
    ETL Listed
    Yes
    Energy Star Listed
    Yes
    AHRI Certified
    Yes
    ISO Certified
    Yes
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Limited* 10 Years Years
    Compressor Warranty
    LIFETIME Years
