Goodman 80% AFUE 100,000 BTU 2 Stage Upflow Variable Speed Gas Furnace

Name: Goodman 80% AFUE 100,000 BTU 2 Stage Upflow Variable Speed Gas Furnace
Brand: Goodman
SKU: 26169
Price: 1820.00 USD
Availability: OutOfStock

Model: GMVC81005CN Item Number: 26169

Ask a Question

Enlarge Image

View All

Add to Cart Form

Product Discontinued

Sorry, this product is no longer available.

Try This Instead

Goodman GMVC80 - 100k BTU - Two-Stage Gas Furnace - 80% AFUE

Model:

GMVC801005CN

$2,144.00

481 In-Stock

Specification Highlights

Condition

New

This product is new and has never been used. It's in its original packaging, which has not been opened.

Weight

112 Pounds

Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.

Type

Gas Furnace

Product Line

GMVC80

Recommended Accessories

Required Accessories Add All Required

Installation Accessories

Features

Overview for Goodman GMVC81005CN

Goodman established itself as the largest HVAC manufacturer in the US by producing high-quality, efficient equipment and providing it to homeowners at a great value. The GMVC8 two-stage furnace utilizes Goodman's superior heat exchanger design to provide efficient, reliable heating to your home. It is equipped with an advanced variable-speed blower motor, which scales circulation to the specific demands of your application in real-time. The GMVC81005CN was designed with multiple options for the unit's orientation, ensuring a painless and quick installation. It even features a self-diagnosing control board that makes maintenance a breeze. If you're looking for consistent comfort and incredible efficiency from a two-stage furnace, it's tough to beat Goodman's GMVC8.

Advanced Heat Exchanger Design

The GCVC80 furnace employs a reliable heavy-duty tubular heat exchanger design. Aluminized steel is used for incredibly efficient heat transfer, and a wrinkle-bend is applied to the tubes to enhance the heat exchanger's dependability and longevity.

Variable Speed ECM Motor

The GMVC80 features an efficient and quiet variable speed motor that ramps up or down according to the heating or cooling demand, providing accurate temperature control and keeping money spent on utility bills in your pocket.

Quiet Comfort

The blower and gas valve of the GMVC80 were selected for their incredibly low sound levels. Additionally, this unit offers an airflow system and fan speed options that allow it to operate quietly while providing consistent comfort.

Secure Cabinet

All GMVC80 furnaces are protected by a durable steel cabinet rated for less than 2% air leakage. The heat exchanger section is insulated to prevent heat loss and the return side of the cabinet is solid and airtight.

ComfortBridge Technology

This furnace is equipped with Goodman's ComfortBridge technology that continuously monitors system performance for customized indoor comfort.

Extended Warranty

Goodman offers a 10-year limited unit replacement and parts warranty when you register your product online within 60 days of installation. An unregistered product has the standard 5-year warranty. See the "Manuals" tab for more information.

Specifications

General Information

Type

Gas Furnace

Product Line

GMVC80

Fuel Type

To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.

Natural Gas

Vent Type

Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.

Chimney Vent

Modulating/Staging

Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control.

Two Stage

Blower Motor Speed

ECM Variable-Speed

Configuration

Orientation describes the direction that air will flow through a piece of equipment. (e.g. air will flow horizontally through a "Horizontal" unit heater.) Most equipment will only function properly if installed in the proper orientation.

Upflow/Horizontal

Gas Conversion Kit

Available

UPC

663051567443

Performance

AFUE

AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace.

80 %

Heating BTU

100000

High Fire Input

100000 BTU

High Fire Output

80000 BTU

Low Fire Input

70000 BTU

Low Fire Output

56000 BTU

Maximum Air Flow

2000 CFM

Ultra Low NOx Emissions

NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx.

Low NOx Emissions

NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Low NOx appliances emit less than 40 ng/J (nanogram per Joule) of NOx.

Electrical Data

Voltage

115 Volts

Phase

Frequency

60 Hz

Minimum Circuit Ampacity

10.6 Amps

Recommended Breaker Size

15 Amps

Dimensions

Flue Connection Size

4 Inches

Cabinet Width

21 Inches

Product Height

33 1/2 Inches

Product Width

21 Inches

Product Depth

28 Inches

Product Weight

112 Pounds

Shipping Weight

112 Pounds

Certifications

Country of Origin

United States

ETL Listed

Yes

AHRI Certified

Yes

ISO Certified

Yes

AHRI Reference Number

202327714

Warranty Information

Unit Replacement Warranty

10 Years

Parts Warranty

A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More

10 Years

Heat Exchanger Warranty

Lifetime Years
