Generac 400-Amp Automatic Smart Transfer Switch w/ Power Management

Model: RTSC400A3 Item Number: 50719
Generac RTSC400A3
PREVIOUS
NEXT
Generac RTSC400A3
Enlarge Image
Our Price: $2,129.00
Factory-Direct
Ships in 2-3 Weeks
Generac 400-Amp Automatic Smart Transfer Switch w/ Power Management
Generac 400-Amp Automatic Smart Transfer Switch w/ Power Management Model: RTSC400A3 Item Number: 50719
$2,129.00
Factory-Direct
-
+
Accessories
Features
Specifications
Reviews
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Truck Icon
Free Lift Gate Learn More
Free Lift Gate
*This product qualifies for Free Lift Gate Service. Items over 100lbs normally ship via semi-truck. Select this service if you need the product lowered to the ground curbside. To learn more about Lift Gate Service, read our shipping policy.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Generator Transfer Switches
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Generac RTSC400A3

  • 400-Amp Automatic Transfer Switch w/ Power Management
  • For Generac Evolution™ & Generac Nexus™ Controllers
  • Designed For Standard Installation
  • Requires a sub-panel for overload protection
  • Digital Power Management Technology (DPM)
  • Allows your generator to work smarter, not harder
  • Be Smart....Get More Out Of Your Generator
  • Cycles power on and off as needed for different appliances
  • Manage Up To (4) Individual HVAC Loads - No Hardware Rec'd
  • Great for homes with multiple Air conditioners (24 VAC controlled)
  • Add Up To (8) Generac Load Managers (Sold Separately)
  • Frequency (Hz) monitoring design, no control wire required
  • Versatile design, easily prioritize loads & lock-out non-essential loads
  • NEMA 3R Indoor/Outdoor Rated
  • Steel, wall mountable weather-proof enclosure
  • Electrostatically applied and baked powder coating paint (Gray)
  • Tech Spec Summary: Only For Use w/ Generac Generators
  • Load Transition Type: Open Transition
  • Withstand Rating: 22,000 Amps --- Lug Range: #4 or 1/0 - 250 MCM
  • 5-Year Limited Warranty - UL Listed
  • Specifications
    View More

    Specifications

    General Information
    Product Category
    Generator Transfer Switches
    Overview
    Product Category
    Generator Transfer Switches
    Weight
    133 Pounds
    Made in USA
    Yes
    Consumer Warranty
    5 Years
    Product Length
    36 Inches
    Product Width
    24 Inches
    Product Height
    10 Inches
    UPC
    696471619867
    Product Specs
    Voltage
    120/240 Single-Phase
    Frequency
    60 Hertz
    Rated Watts
    96000 Watts
    Rated Amps
    400 Amps
    Enclosure
    NEMA 3R
    Transfer Switch Style
    Standard Installation
    ATS Load Prioritizing
    Compatible
    ATS Load Shedding
    Compatible
    ATS Poles
    2 Poles
    ATS Service Disconnect
    No
    Max Utility Input
    400 Amps
    Max Generator Input
    400 Amps
    Maximum Wattage
    96000 Watts
    UL Listed
    Yes
