Fujitsu 12,000 BTU Ductless Wall Mounted Heat Pump Air Handler

Name: Fujitsu 12,000 BTU Ductless Wall Mounted Heat Pump Air Handler
Brand: Fujitsu
SKU: 65389
Price: 532.00 USD
Availability: InStock
Rating: 1.00 (1 reviews)

Model: ASU12RLF1 Item Number: 65389

(1)

Ask a Question

Enlarge Image

View All

Our Price: $532.00

In-Stock

Ships in 4-7 Days

Fujitsu 12,000 BTU Ductless Wall Mounted Heat Pump Air Handler Model: ASU12RLF1 Item Number: 65389

$532.00

In-Stock

Accessories

Features

Specifications

Reviews

Product Q&A

Manuals

Free Shipping

*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.

Low Price Guarantee

Shop with Confidence knowing you have the Right system at the Right Price and shipped Right Away.

We strive to give our customers the best price and service possible. If you happen to find a better price on your product(s) up to 30 days after your purchase let us know and we will match the price of any online competitor.

Simply call our sales or customer service department at 866-631-6389 and one of our representatives will be happy to price match the product(s) for you.

Specification Highlights

Condition

New

This product is new and has never been used. It's in its original packaging, which has not been opened.

Weight

23 Pounds

Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.

Type

Wall Mounted

Product Line

Halcyon HFI

Capacity (BTU/h)

Recommended Accessories

Required Accessories Add All Required

Installation Accessories

Features

Overview for Fujitsu ASU12RLF1

Please Note: Due to the limited availability of this model, these products will be sold in systems only. Should you have any questions please contact our sales center at 866-631-6389 option 1 for alternate options.

Overview for Fujitsu ASU12RLF1Stylish, slim and elegant, these popular wall mounted units are designed for single rooms. Indoor units have a clean, aesthetic design and are small but mighty and shorter in length than competing units, helping them blend into any room. The Fujitsu ASU12RLF1 is a ENERGY STAR qualified heat pumps, meaning they save you money on your utility bill and provide both heating and cooling. This is an indoor unit only, and requires an outdoor unit to function. Outdoor unit must be purchased separately.

Auto Restart/Reset

Minimum Heat Mode

Auto Mode

Dry Mode

24-Hour Timer

Sleep Timer

Ion Deoderizing Filter

Apple Catechin Filter

Our SKU number(s): Fujitsu ASU12RLF1

The manufacturer model number(s): Fujitsu ASU12RLF1

Product Note

This product requires a compatible mini split outdoor condenser and the following accessories for indoor unit installation:

Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.

Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing..

Disconnect Box & Electrical Whip Kit - The Disconnect Box & Whip Kit provides a safe and simple way to connect your outdoor condenser to your fuse box.

Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.

Outdoor Condenser Plastic Pad (Optional) - This pad provides an even surface, free of debris, on which to place your outdoor condenser.

Wall Bracket (Optional) - A simple and sturdy way to mount your outdoor condenser off of the ground.

Adding these accessories to your order will provide a complete, ready-to-install mini split system.

Specifications

General Information

Type

Wall Mounted

Product Line

Halcyon HFI

Operating Mode

Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements.

Heating and Cooling

Multi-Zone Compatible

Yes

Refrigerant Type

R-410A

Remote Control

Wireless

Indoor Unit Size(s)

Mini split systems can have one or more indoor units connected to a single outdoor unit. Indoor Unit Size(s) specifies what indoor unit sizes are used in a system. We have combined 6k and 7k indoor units to enhance searchability.

Installation Location

Indoor

Performance

Cooling BTU

12000

Cooling Capacity

12000 BTU

Maximum Air Flow

388 CFM

Minimum Air Flow

182 CFM

Minimum Sound Level

21 dB

Maximum Sound Level

Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.

40 dB

Electrical Data

Phase

Frequency

60 Hz

Dimensions

Gas Connection Size

3/8 Inch

Liquid Connection Size

1/4 Inch

Product Height

10 1/2 Inches

Product Width

33 1/16 Inches

Product Depth

8 Inches

Product Weight

23 Pounds

Shipping Height

10 5/8 Inches

Shipping Width

34 13/16 Inches

Shipping Depth

14 3/4 Inches

Shipping Weight

23 Pounds

Certifications

ETL Listed

Yes

AHRI Certified

Yes

ISO Certified

Yes

Warranty Information

Parts Warranty

A warranty is a safeguard from defects in manufacturing and can vary in length and terms. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More

5 Years

Reviews

(1)

Reviews

Product Q&A

Be the first to ask a question.

Whether it's a general or technical question ACWholesalers can help. Our customer service team is backed by years of experience so you can have confidence knowing that you'll be getting an insightful response.

Manuals

Fujitsu ASU12RLF1 Submittal

Fujitsu ASU12RLF1 Operation Manual

Fujitsu ASU12RLF1 Installation Manual
