Fantech 2494 CFM 18" Duct Square Centrifugal Mixed Flow Inline Fan

Model: FSD18 Item Number: 31194
Fantech FSD18
PREVIOUS
NEXT
Fantech FSD18
Enlarge Image
Our Price: $988.00
synchrony card icon
$165 / Month
Suggested monthly payments with 6 month financing.
Only 1 In-Stock
Ships Wednesday, June 26th
Shipping to60601
Fantech 2494 CFM 18
Fantech 2494 CFM 18" Duct Square Centrifugal Mixed Flow Inline Fan Model: FSD18 Item Number: 31194
$988.00
Only 1 In-Stock
-
+
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Truck Icon
Free Lift Gate Learn More
Free Lift Gate
*This product qualifies for Free Lift Gate Service. Items over 100lbs normally ship via semi-truck. Select this service if you need the product lowered to the ground curbside. To learn more about Lift Gate Service, read our shipping policy.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Fans
    UPC
    650737131807
Duct Diameter
Select Attribute
Features
View More

Features

Overview for Fantech FSD18

The Fantech FSD 18 Square Inline Duct Fan is a 2,463 CFM centrifugal supply and exhaust fan designed to provide high airflow for areas with limited space. It is constructed for 18 inch square venting. FSD Series Duct Fans can install directly within equally sized square ductwork without the need for transitions. This unit is wired for 115 volts.
  • Backward Curved Impeller
  • Backward curved impeller blades allow particles to easily pass through the fan blades, preventing a build-up.
  • 100% Speed Controllable
  • On-demand ventilation and precision balancing of systems is controllable through voltage reduction.
  • External Rotor Motor
  • An external rotor motor allows the fan to operate in high-moisture or dust-laden areas.
  • Thermal Overload Protection
  • Thermal overload protection automatically resets the fan when temperatures get too high, avoiding potential damage to the unit due to overheating.
  • Specifications
    View More

    Specifications

    Overview
    Product Category
    Fans
    UPC
    650737131807
    General Information
    Type
    Duct Fan
    Product Line
    FSD
    Product Category
    Fans
    Mount Type
    Inline
    Housing Material
    Galvanized Steel
    Performance
    Maximum Air Flow
    2463 CFM
    Maximum Sound Level Learn More
    Maximum Sound Level
    The sone is a unit of loudness, or how loud a sound is perceived. For reference, the loudness of rustiling leaves is around 0.02 sones, a quiet running refrigerator is around 2 sones, and a running car is around 4-16 sones.
    12.4 Sones
    Electrical Data
    Voltage
    115 Volts
    Phase
    1
    Frequency
    60 Hz
    Current Draw
    4.8 Amps
    Dimensions
    Duct Connection
    18 Inches
    Product Height
    17 5/8 Inches
    Product Width
    17 5/8 Inches
    Product Length
    15 3/4 Inches
    Shipping Height
    20 Inches
    Shipping Width
    24 Inches
    Shipping Length
    24 Inches
    Certifications
    UL Listed
    Yes
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    3 Years
