Fantech 245 CFM Central Vent Centri. Multi-Port Exhaust Fan, 2 Point

Model: CVS275A Item Number: 31261
Fantech CVS275A
PREVIOUS
NEXT
Fantech CVS275A
Enlarge Image
Our Price: $281.00
synchrony card icon
$47 / Month
Suggested monthly payments with 6 month financing.
In-Stock
Ships Monday, October 14th
Shipping to60601
Fantech 245 CFM Central Vent Centri. Multi-Port Exhaust Fan, 2 Point
Fantech 245 CFM Central Vent Centri. Multi-Port Exhaust Fan, 2 Point Model: CVS275A Item Number: 31261
$281.00
In-Stock
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Product Category
    Fans
    UPC
    650737332754
Max Air Flow (CFM)
Select Attribute
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Fantech CVS275A

The Fantech CVS 275A Multi-Port Fan is designed for areas where ventilation is needed but space is limited. Commonly installed in the spaces between floors, the CVS 275A is a 2 port centrifugal fan with a maximum airflow of 245 CFM. Multi-port fans allow several exhaust points to connect to one centrally located fan. CVS Series fans are engineered for vibration free, quiet performance. They are capable of handling air flows up to 140 degrees Fahrenheit. Each unit is constructed with a galvanized steel housing and an external rotor motor with a backward-curved centrifugal fan wheel.
  • Permanently Lubricated Sealed Ball Bearings
  • Permanently lubricated sealed ball bearings extend the service life of your fan.
  • 100% Speed Controllable
  • On-demand ventilation and precision balancing of systems is controllable through voltage reduction.
  • External Rotor Motor
  • An external rotor motor allows the fan to operate in high-moisture or dust-laden areas.
  • Specifications
    View More

    Specifications

    Overview
    Product Category
    Fans
    UPC
    650737332754
    General Information
    Type
    Ventilation Fan
    Product Line
    CVS
    Product Category
    Fans
    Ports Quantity
    2
    Housing Material
    Galvanized Steel
    Performance
    Maximum Air Flow
    245 CFM
    Electrical Data
    Voltage
    115 Volts
    Phase
    1
    Frequency
    60 Hz
    Current Draw
    0.79 Amps
    Dimensions
    Duct Connection
    5 Inches
    Product Height
    7 5/8 Inches
    Product Width
    12 Inches
    Product Length
    11 Inches
    Shipping Height
    12 Inches
    Shipping Width
    17 Inches
    Shipping Length
    17 Inches
    Shipping Weight
    15 Pounds
    Intake Diameter
    5 Inches
    Exhaust Diameter
    6 Inches
    Certifications
    CSA Listed
    Yes
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    5 Years
    Reviews
    View More

    Reviews

    Do You Own This Product?

    Give us your opinion on this product and help any future buyer's make an informed decision.

    Product Q&A
    View More

    Product Q&A

    Be the first to ask a question.

    Whether it's a general or technical question ACWholesalers can help. Our customer service team is backed by years of experience so you can have confidence knowing that you'll be getting an insightful response.
