Electro Industries EZB-Eco - 4 Stg - Modulating, (2) 60A Breakers - 20 kW - 68,200 BTU

Model: EZB-T1-20-240-1 Item Number: 110255
Electro Industries EZB-T1-20-240-1
PREVIOUS
NEXT
Electro Industries EZB-T1-20-240-1
Enlarge Image
Our Price: $3,987.00
synchrony card icon
$70 / Month
With our 86 months 11.99% APR*
86 fixed monthly payments required.
Factory-Direct
Ships in 2-3 Weeks
Electro Industries EZB-Eco -  4 Stg - Modulating, (2) 60A Breakers - 20 kW - 68,200 BTU
Electro Industries EZB-Eco - 4 Stg - Modulating, (2) 60A Breakers - 20 kW - 68,200 BTU Model: EZB-T1-20-240-1 Item Number: 110255
$3,987.00
Factory-Direct
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
Truck Icon
Free Lift Gate Learn More
Free Lift Gate
*This product qualifies for Free Lift Gate Service. Items over 100lbs normally ship via semi-truck. Select this service if you need the product lowered to the ground curbside. To learn more about Lift Gate Service, read our shipping policy.
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    140 Pounds Learn More
    140 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Product Category
    Boiler
Electric Heat Capacity (kW)
Select Attribute
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Electro Industries EZB-T1-20-240-1

Designed for radiant floor heating or hot water baseboard applications, the Electro Industries EZB-Eco is a complete boiler system in one simple package. Built with contractors in mind, the EZB-Eco includes an ASME pressure vessel, pre-charged expansion tank, relief valve, air eliminator and circulation pump for simple installation. The EZB-Eco features modulating operation with 100% efficiency, effectively warming your home to desired temperatures without breaking the bank on energy bills. Like all electric boilers, the EZB-Eco is safe to operate and can be installed almost anywhere in your home.
  • Electro Industries EZB-Eco Features
  • Temperature Sensing
  • WarmFlo Modulation Control
  • Outdoor Reset Capability
  • ETL/Intertek Listed
  • Product Includes
  • ASME Pressure Vessel
  • Incoloy Heating Elements
  • Pressure/Temperature Gauge
  • Supply & Outdoor Temperature Sensors
  • 30 psi Relief Valve
  • Air Eliminator
  • Pre-charged 12 psi Expansion Tank
  • Circulating Pump with Isolation Flanges
  • Circuit Breakers
  • Specifications
    View More

    Specifications

    Overview
    Product Category
    Boiler
    General Information
    Product Line
    EZB-Eco
    Product Category
    Boiler
    Medium Learn More
    Medium
    Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
    Hot Water
    Fuel Type Learn More
    Fuel Type
    To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
    Electric
    Modulating/Staging Learn More
    Modulating/Staging
    Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control.
    Modulating
    Mount Type
    Wall
    Includes Pump
    Yes
    Assembly Type
    Packaged
    Performance
    Heating Capacity
    68200 BTU
    Heating Capacity (kW)
    20 kW
    Ultra Low NOx Emissions Learn More
    Ultra Low NOx Emissions
    NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx.
    Yes
    Electrical Data
    Voltage
    240 Volts
    Phase
    1
    Frequency
    60 Hz
    Current Draw
    83.3 Amps
    Dimensions
    Supply Connection
    1 Inch
    Return Connection
    1 Inch
    Product Height
    36 Inches
    Product Width
    25 Inches
    Product Depth
    13 Inches
    Product Weight
    140 Pounds
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    2 Years
    Heating Element Warranty
    20 Years
    Vessel Warranty
    20 Years
