Mitsubishi M-Series - System Control Interface
Mitsubishi M-Series - System Control Interface Model: MAC-334IF-E Item Number: 106977
$270.00
In-Stock
-
+
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges map apply, see our full shipping policy for more details.
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Ask A Question
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    0.79375 Pounds Learn More
    0.79375 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Product Category
    Mini Split Accessories
View More
Features
View More

Features

Overview for Mitsubishi MAC-334IF-E

The MAC-334IF-E system control interface allows select M-Series mini split indoor units to connect to Mitsubishi's PAR-40MAAU wired remote controller. The MAC-334IF-E also allows M-Series indoor units to communicate with the CITY MULTI® Controls Networks via M-Net, includes a Dual Auto mode setting configured by dip switch, and provides an input to allow remote On/Off control of an indoor unit.
  • Product Compatible With
  • MSY/MSZ-D Wall Mounted Units (NA-8 Only)
  • MSZ-EF Wall Mounted Units
  • MSZ-FE Wall Mounted Units (09(12)NA-8 and 18NA)
  • MSZ-FH Wall Mounted Units
  • MSY/MSZ-GE Wall Mounted Units (NA-8, NA-9 and GE24NA)
  • MSY/MSZ-GL Wall Mounted Units
  • MSZ-HM Wall Mounted Units
  • MSZ-JP Wall Mounted Units
  • MSZ-WR Wall Mounted Units
  • MFZ-KA Floor Standing Units
  • MLZ-KP One-Way Ceiling Cassette Units
  • See Compatibility Chart under the "Manuals" tab for more information
  • Product Includes
  • (1) Interface Unit with 5-Core Connecting Cable
  • (1) Set of 3-Core Lead Wires
  • (1) Adhesive-Backed Cushioning Material
  • (2) Small Mounting Cord Clamps
  • (4) Medium Mounting Cord Clamps
  • (3) Large Mounting Cord Clamps
  • (9) Cable Ties
  • (5) Wire Fasteners
  • (1) 4x10 Mounting Screw
  • (1) 4x16 Mounting Screw
  • (6) 3.4x12 Mounting Screws
    • Specifications
    View More

    Specifications

    Overview
    Product Category
    Mini Split Accessories
    General Information
    Type
    Adapter
    Product Line
    M-Series
    Product Category
    Mini Split Accessories
    Power Source
    External - 12VDC
    Performance
    Minimum Operating Temperature
    32 F
    Maximum Operating Temperature
    104 F
    Dimensions
    Product Height
    2 1/8 Inches
    Product Width
    6 5/16 Inches
    Product Depth
    2 3/4 Inches
    Product Weight
    0.79375 Pounds
    Warranty Information
    Parts Warranty Days
    90
