Williamson 73K BTU 92.4% AFUE Combi NG Boiler Direct Vent

Model: FS-80 COMBI Item Number: 58496
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Williamson-Thermoflo FS-80 COMBI
PREVIOUS
NEXT
Williamson-Thermoflo FS-80 COMBI
Williamson-Thermoflo FS-80 COMBI
Enlarge Image
Williamson-Thermoflo FS-80 COMBI
Williamson-Thermoflo FS-80 COMBI
View All
Product Discontinued
Sorry, this product is no longer available.
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    70 Pounds Learn More
    70 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Product Category
    Boiler
    UPC
    811175015566
View More
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Williamson-Thermoflo FS-80 COMBI

Keep your home warm and heating costs low with the Williamson-Thermoflo Freestyle combi-boiler. The Freestyle FS-80 COMBI boasts an impressive 92.2% AFUE efficiency rating, making it one of the most efficient boilers on the residential market. Easy to install and even simpler to maintain, the Freestyle boiler comes with a wall mount allowing it to fit into almost any space with its compact design. A crystal clear digital display allows for easy access to important information as well as the ability to quickly and easily adjust any of the boilers settings. The FS-80 COMBI comes standard with multiple features designed to keep energy costs down, including its modulating combustion system, allowing the FS-80 COMBI to run reliably while saving you money. As a Combi model, this boiler comes with a built in domestic hot water heater and circulator pump, allowing it to provide endless hot water to your showers, sinks, and home appliances. The Freestyle series runs standard on natural gas, but can be converted to propane with a simple adapter, making it flexible enough to be used in any home.
  • Higher Efficiency, Lower Costs
  • With an AFUE efficiency rating above 92%, the Freestyle boiler is one of the most efficient on the market. With its ASME rated heat exchanger and modulating burner, it will not only lower energy costs, but help reduce your carbon footprint as well.
  • Factory Tested
  • All Freestyle boilers come factory tested and certified by top industry analysts ensuring they will remain reliable and efficient for years to come.
  • Unmatched Flexibility
  • Each Freestyle comes with its own wall mounting kit. Combined with the boiler's compact design and multiple venting options, the Freestyle boiler can fit into nearly any residential space.
  • Built in Hot Water Heater
  • The Freestyle Combi models come with a built in tankless water heater. Using its built-in flat plate heat exchanger, the Freestyle Combi unit can provide hot water for your entire home.
  • Product Includes
  • (1) FS-80 COMBI Freestyle Boiler
  • (1) 640-000-044WT Wall-Mount Kit
  • (1) 640-000-037WT Condensate Trap Kit
  • (1) 640-000-017WT FX3-FP Circulator
    • Specifications
    View More

    Specifications

    Overview
    Product Category
    Boiler
    UPC
    811175015566
    General Information
    Product Line
    Freestyle
    Product Category
    Boiler
    Medium Learn More
    Medium
    Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
    Hot Water
    Fuel Type Learn More
    Fuel Type
    To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
    Natural Gas
    Combustion Type Learn More
    Combustion Type
    Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
    Condensing
    Vent Type Learn More
    Vent Type
    Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
    Direct Vent
    DHW Production Learn More
    DHW Production
    DHW (Domestic Hot Water) is potable water for uses other than space heat. Some boilers are able to provide DHW "out of the box", while others can do so with the purchase of optional accessories.
    Yes
    Modulating/Staging Learn More
    Modulating/Staging
    Stages are unique speeds or levels that equipment can operate at. More stages allow for better fine-tuned control of output, which improves comfort and efficiency. Modulating equipment can operate across a range of levels, giving the highest level of fine-tuned control.
    Modulating
    Connection Type
    NPT
    Mount Type
    Wall
    Minimum Altitude
    0 Feet
    Maximum Altitude
    10000 Feet
    Assembly Type
    Packaged
    Includes Pump
    Yes
    Gas Conversion Kit
    Available
    Performance
    AFUE Learn More
    AFUE
    AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace.
    92 %
    Maximum Input Capacity Learn More
    Maximum Input Capacity
    The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
    80000 BTU
    Minimum Input Capacity
    8000 BTU
    DOE Heating Capacity Learn More
    DOE Heating Capacity
    Also referred to as Gross Output, this is the output of a boiler after accounting for combustion efficiency. We recommend sizing hot water boilers based on the DOE Heating Capacity.
    73000 BTU
    Net I=B=R Capacity Learn More
    Net I=B=R Capacity
    I=B=R, also referred to as Net Output or AHRI Capacity, is the rated heat output of a boiler after accounting for combustion efficiency, piping loss, and an extra pickup factor. We recommend sizing steam boilers based on the I=B=R rating.
    63000 BTU
    Ultra Low NOx Emissions Learn More
    Ultra Low NOx Emissions
    NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx.
    Yes
    Turndown Ratio
    10:1
    Electrical Data
    Phase
    1
    Frequency
    60 Hz
    Dimensions
    Flue Connection Size
    3 Inches
    Gas Connection Size
    1/2 Inch
    Supply Connection
    3/4 Inch
    Return Connection
    3/4 Inch
    Product Height
    23 5/8 Inches
    Product Width
    15 3/4 Inches
    Product Depth
    12 29/48 Inches
    Product Weight
    70 Pounds
    Shipping Weight
    80 Pounds
    Certifications
    ETL Listed
    Yes
    Energy Star Listed
    Yes
    ASME Certified
    Yes
    AHRI Certified
    Yes
    ISO Certified
    Yes
    AHRI Reference Number
    7470131
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    2 Years
    Heat Exchanger Warranty
    10 Years
