Goodman - 3.5 Ton Cooling - 100k BTU/Hr Heating - Air Conditioner + Variable Speed Furnace Kit - 13.5 SEER - 97% AFUE - For Horizontal Installation

Model: GSX1342GMVM97100H Item Number: 75533
Ask a Question
Goodman GSX1342GMVM97100H
PREVIOUS
NEXT
Goodman GSX1342GMVM97100H
Watch Video
Watch Video
Watch Video
Watch Video
Watch Video
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Enlarge Image
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Watch Video
Goodman GSX1342GMVM97100H
Watch Video
Goodman GSX1342GMVM97100H
Watch Video
Goodman GSX1342GMVM97100H
Watch Video
Goodman GSX1342GMVM97100H
Watch Video
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
Goodman GSX1342GMVM97100H
View All
Originally $4,242.00
Add to Cart for Lower Price
synchrony card icon
$67 / Month
With our 86 months 11.99% APR*
86 fixed monthly payments required.
Ships in 4-6 Weeks
Goodman - 3.5 Ton Cooling - 100k BTU/Hr Heating - Air Conditioner + Variable Speed Furnace Kit - 13.5 SEER - 97% AFUE - For Horizontal Installation
Goodman - 3.5 Ton Cooling - 100k BTU/Hr Heating - Air Conditioner + Variable Speed Furnace Kit - 13.5 SEER - 97% AFUE - For Horizontal Installation Model: GSX1342GMVM97100H Item Number: 75533
-
+
Accessories
Features
Specifications
Reviews
Product Q&A
Manuals
Shipping Crate Icon
Free Shipping Learn More
Truck Icon
Free Lift Gate Learn More
Specification Highlights
    Condition
    New Learn More
    Weight
    378 Pounds Learn More
    Operating Mode
    Heating and Cooling
    Modulating/Staging
    Modulating
View More
Bundle Includes 3 items
  • product image
    (1) Goodman 97% AFUE 100,000 BTU Variable Speed Upflow Gas Furnace (GMVM971005CN)
  • product image
    (1) Goodman 3.5 Ton 13 SEER Air Conditioner Condenser w/ R410A Refrigerant (GSX130421)
  • product image
    (1) Goodman 3 to 3.5 Ton 21 in. High Air Conditioner Horizontal Cased Coil (CHPF3743C6)
View Full Bundle
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features & Bundle Details
View More

Features & Bundle Details

Overview for Goodman GSX1342GMVM97100H

A Goodman central air and furnace kit is the perfect way to update your home's HVAC system. This kit contains a GSX13 air conditioner, a GMVM97 furnace, and a cased evaporator coil making it the ideal solution for the northern parts the country. It's the perfect kit for areas that use a less than average amount of cooling but want an efficient variable speed furnace for the long cold winters. Each of these components is designed with a focus on ease-of-installation and durability to provide you with upfront and long-term value. If you're looking for a complete comfort solution backed by superior craftsmanship, the Goodman GSX1342GMVM97100H air conditioner and furnace kit fits the bill perfectly.
  • The manufacturer model number(s): Goodman GSX130421 GMVM971005CN CHPF3743C6
  • AHRI Reference Number: 7354035 * *May change based on the Manufacturer revision
  • Product Note
    The recommended line set size for this system will vary based on the length of line set you require for installation. Compatible line sets can be found under the "Recommended Accessories" tab. | The US Department of Energy regulates minimum efficiency standards for central air conditioners and heat pumps based on geographic regions. We are required to abide by these regulations when selling products, and take this responsibility seriously. The standards depend on the rated efficiency of the entire system, not the nominal efficiencies of individual components. If you are unsure if your system will be compliant, please call or email us for help.
    Bundle Includes 3 items
    Specifications
    View More

    Specifications

    Included In This Bundle

    Bundle Overviewgrey arrow icon
    Bundle Overview
    GMVM971005CN Specifications
    GSX130421 Specifications
    CHPF3743C6 Specifications
    General Information
    Operating Mode Learn More
    Heating and Cooling
    Modulating/Staging Learn More
    Modulating
    Blower Motor
    ECM Variable-Speed
    Coil Width
    21 Inches
    Configuration Learn More
    Horizontal
    DOE Regional Compliance Learn More
    Nationwide (Except CA, TX and UT)
    Performance
    AFUE Learn More
    97 %
    Capacity Learn More
    3.5 Tons
    Cooling Capacity
    40500 BTU
    Nominal Cooling Capacity
    42000 BTU
    Heating BTU
    100000
    SEER Learn More
    13.5
    EER Learn More
    11.3
    Maximum Air Flow
    1300 CFM
    Dimensions
    Product Weight
    378 Pounds
    Shipping Weight
    396 Pounds
    Certifications
    ETL Listed
    Yes
    AHRI Certified
    Yes
    AHRI Reference Number
    7354035
    General Information
    Type
    Gas Furnace
    Product Line
    GMVM97
    Fuel Type Learn More
    Natural Gas
    Vent Type Learn More
    Direct Vent
    Modulating/Staging Learn More
    Modulating
    Blower Motor
    ECM Variable-Speed
    Configuration Learn More
    Upflow/Horizontal
    Gas Conversion Kit
    Available
    Installation Available
    Yes
    Performance
    AFUE Learn More
    97 %
    Heating BTU
    100000
    High Fire Input
    100000 BTU
    High Fire Output
    97000 BTU
    Low Fire Input
    50000 BTU
    Low Fire Output
    48500 BTU
    Maximum Air Flow
    2000 CFM
    Ultra Low NOx Emissions Learn More
    No
    Low NOx Emissions Learn More
    Yes
    Electrical Data
    Voltage
    115 Volts
    Phase
    1
    Frequency
    60 Hz
    Minimum Circuit Ampacity
    15.4 Amps
    Recommended Breaker Size
    15 Amps
    Dimensions
    Flue Connection Size
    2 or 3 Inches
    Cabinet Width
    21 Inches
    Product Height
    34 1/2 Inches
    Product Width
    21 Inches
    Product Depth
    28 3/4 Inches
    Product Weight
    144 Pounds
    Shipping Weight
    144 Pounds
    Certifications
    ETL Listed
    Yes
    Energy Star Listed
    Yes
    AHRI Certified
    Yes
    ISO Certified
    Yes
    AHRI Reference Number
    7424268
    Warranty Information
    Unit Replacement Warranty
    10 Years
    Parts Warranty Learn More
    5 Years
    Heat Exchanger Warranty
    20 Years
    General Information
    Type
    Condenser
    Product Line
    GSX13
    Operating Mode Learn More
    Cooling
    Refrigerant Type
    R-410a
    Installation Location
    Outdoor
    Compressor Stages Learn More
    Single
    DOE Regional Compliance Learn More
    North
    Installation Available
    Yes
    Performance
    Capacity Learn More
    3.5 Tons
    Cooling BTU
    42000
    Cooling Capacity
    42000 BTU
    SEER Learn More
    13.0
    EER Learn More
    11.0
    Maximum Sound Level Learn More
    75 dB
    Electrical Data
    Voltage
    208/230 Volts
    Phase
    1
    Frequency
    60 Hz
    Minimum Circuit Ampacity
    24 Amps
    Recommended Breaker Size
    40 Amps
    Dimensions
    Suction Connection Size
    1 1/8 Inches
    Liquid Connection Size
    3/8 Inch
    Product Height
    36 1/4 Inches
    Product Width
    29 Inches
    Product Depth
    29 Inches
    Product Weight
    171 Pounds
    Shipping Weight
    189 Pounds
    Certifications
    Country of Origin
    United States
    ETL Listed
    Yes
    AHRI Certified
    Yes
    ISO Certified
    Yes
    Warranty Information
    Parts Warranty Learn More
    Limited* 10 Years Years
    General Information
    Type
    Evaporator Coil
    Product Line
    CHPF
    Refrigerant Type
    R-410A
    Casing
    Cased
    Style
    A Coil
    Configuration Learn More
    Horizontal
    Installation Available
    Yes
    Performance
    Capacity Learn More
    3.0 - 3.5 Tons
    Cooling BTU
    42000
    Nominal Minimum Cooling Capacity
    36000 BTU
    Dimensions
    Suction Connection Size
    7/8 Inch
    Liquid Connection Size
    3/8 Inch
    Cabinet Width
    21 Inches
    Product Height
    21 Inches
    Product Width
    26 Inches
    Product Depth
    21 1/8 Inches
    Product Weight
    63 Pounds
    Shipping Weight
    73 Pounds
    Certifications
    ETL Listed
    Yes
    AHRI Certified
    Yes
    Warranty Information
    Warranty Learn More
    5 Years
