Burnham X-C120 112K BTU 94.0% AFUE Hot Water Boiler NG Direct Vent

Model: X-C120A-4L02 Item Number: 93199
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Burnham X-C120A-4L02
PREVIOUS
NEXT
Burnham X-C120A-4L02
Enlarge Image
Product Discontinued
Sorry, this product is no longer available.
0.0 out of 5 stars0.0 out of 5 stars
(0)
Write A Review
Specification Highlights
    Condition
    New Learn More
    New
    This product is new and has never been used. It's in its original packaging, which has not been opened.
    Weight
    86 Pounds Learn More
    86 Pounds
    Total weight of the product and any included accessory/components. This total is not the shipping weight, as it does not include packing material, which may increase the overall shipping weight of this product.
    Medium
    Hot Water
    Fuel Type
    Natural Gas
View More
Recommended Accessories
View More
Required Accessories Add All Required
Installation Accessories
Features
View More

Features

Overview for Burnham X-C120A-4L02

Burnham continues to be on the forefront of home heating technology. The X-C line of condensing boilers offers a value-priced heating solution without compromising performance or efficiency. This feature-packed boiler includes a universal vent connection and a pre-installed wall mount kit for out-of-the-box installation as well as an advanced Sage2.2 boiler control and LCD display. With a 5:1 turndown ratio and an AFUE rating up to 95%, the X-C condensing boilers are perfect for homeowners looking for an upgrade in efficiency at a lower price point.
  • Sage2.2 Control System
  • The Sage2.2 system has a simple touchscreen interface built into the boiler. The system provides step-by-step instructions for changing settings and running system diagnostics, making the X-C one of the most user-friendly boilers on the market.
  • Built for Efficiency
  • The X-C line is designed to be easy to service, allowing for quick, efficient maintenance. Quicker maintenance combined with ease of installation keeps initial and year-to-year costs down, saving money over the lifetime of the boiler.
  • Simple Installation
  • The X-C features a pre-installed hanging bracket and wall mount kit for out-of-the-box installation. The X-C is perfect for retrofits with its universal vent connection.
  • Outdoor Reset Control
  • An outdoor reset sensor is included with every X-C boiler. This sensor allows your boiler temperature to be adjusted relative to the temperature outside, eliminating excess energy use and guaranteeing comfort.
  • Product Includes
  • (1) Pre-Installed Wall Mounting Kit
  • (1) Pre-Installed Hanging Bracket
    • Product Note
    This product can be used with liquid propane or natural gas and is field convertible.
    Specifications
    View More

    Specifications

    General Information
    Medium Learn More
    Medium
    Medium refers to the substance that carries heat through the heating system. Systems are either designed to use either Hot Water or Steam as a medium, and components are usually specific to one or the other.
    Hot Water
    Fuel Type Learn More
    Fuel Type
    To create heat, some form of fuel is required. Fuel Type specifies what the product uses as an input to create heat.
    Natural Gas
    Combustion Type Learn More
    Combustion Type
    Condensing appliances use leftover thermal energy from combustion gases to heat water in a secondary heat exchanger, resulting in higher efficiency and lower exhaust temperature.
    Condensing
    Vent Type Learn More
    Vent Type
    Products that use combustion (burning) of fuel to create heat also create potentially dangerous gasses that need to be exhausted (AKA "Vented"). Depending on the product, venting can be done via a chimney, through a side wall, or use a second vent to provide fresh air to the appliance.
    Direct Vent
    DHW Production Learn More
    DHW Production
    DHW (Domestic Hot Water) is potable water for uses other than space heat. Some boilers are able to provide DHW "out of the box", while others can do so with the purchase of optional accessories.
    No
    Mount Type
    Wall
    Minimum Altitude
    0 Feet
    Maximum Altitude
    2000 Feet
    Includes Pump
    No
    Assembly Type
    Packaged
    Performance
    AFUE Learn More
    AFUE
    AFUE (Annual Fuel Utilization Efficiency) measures the efficiency of combustion equipment over the entire heating season, and is calculated by dividing the amount of energy that is actually heating your home by the total energy contained in the fuel used by the boiler/furnace.
    94 %
    Maximum Input Capacity Learn More
    Maximum Input Capacity
    The Maximum Input Capacity describes how quickly the appliance will use fuel when delivering it's maximum capacity. The units may change depending on the fuel being used.
    120000 BTU
    Minimum Input Capacity
    24000 BTU
    DOE Heating Capacity Learn More
    DOE Heating Capacity
    Also referred to as Gross Output, this is the output of a boiler after accounting for combustion efficiency. We recommend sizing hot water boilers based on the DOE Heating Capacity.
    112000 BTU
    Net I=B=R Capacity Learn More
    Net I=B=R Capacity
    I=B=R, also referred to as Net Output or AHRI Capacity, is the rated heat output of a boiler after accounting for combustion efficiency, piping loss, and an extra pickup factor. We recommend sizing steam boilers based on the I=B=R rating.
    97000 BTU
    Ultra Low NOx Emissions Learn More
    Ultra Low NOx Emissions
    NOx is a byproduct of the combustion process, and it's output is regulated in some jurisdictions. Many regulators mirror SCAQMD rules, which regulate air quality for some parts of Southern California. Ultra Low NOx appliances emit less than 10-14 ng/J (nanogram per Joule) of NOx.
    No
    Turndown Ratio
    5:1
    Electrical Data
    Voltage
    120 Volts
    Frequency
    60 Hz
    Dimensions
    Flue Connection Size
    3 Inches
    Supply Connection
    1 Inch
    Return Connection
    1 Inch
    Product Height
    26 1/4 Inches
    Product Width
    14 Inches
    Product Depth
    17 7/16 Inches
    Product Weight
    86 Pounds
    Certifications
    Country of Origin
    United States
    Energy Star Listed
    Yes
    ASME Certified
    Yes
    AHRI Certified
    Yes
    AHRI Reference Number
    8930880
    Warranty Information
    Parts Warranty Show ACW Parts Warranty Learn More
    Parts Warranty
    A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
    5 Years
